BK-XXX-PS KNX POWER SUPPLY
BK-XXXPS KNX power supplies generate and monitor the KNX system voltage (SELV). They ensure the supply of the KNX subscribers with electrical energy and data communication Via the bus line, which is decoupled from the power supply by an integrated choke.
The BKXXXPS power supplies has two-color LED indicates device output status & The voltage output is short-circuit and overload protected.
| Electrical Parameters | ||||||
| Device Name | BK160PS | BK320PS | BK640PS | |||
| Rated Current | 160Ma | 320mA | 640mA | |||
| Power consumption (min) | 6.6 W | 12.5 W | 24 W | |||
| Power consumption (max) | 21 W | 30 W | 55 W | |||
| Input Voltage | 100 Volt~240 Volt AC | |||||
| Operating frequency | 50/50Hz | |||||
| Channels Number | Single Line with integrated choke | |||||
| Power Supply output | KNX BUS Voltage, 30V DC, -/+2Volt | |||||
| overload, short circuit and over temperature protection | YES | YES | YES | |||
| LED Status | ||||||
| Green: | I < IOVL | |||||
| LED indications | Red: | Overload | ||||
| Red flashing: | Short-circuit | |||||
| Environmental parameters | ||||||
| Operating Humidity | >90 RH | |||||
| Storage Humidity | Up to 92% | |||||
| Operating temperature | -10℃ ~ +45℃ | |||||
| Storage Temperature | -15°C ~ +55°C | |||||
| Transport Temperature | -15°C ~ +60°C | |||||
| Device Parameters | ||||||
| Protection type | IP20 | |||||
| Input type | Single phase | |||||
| Mounting | (35m) Din-Rail | |||||
| Flammability | Non-Flammable Product | |||||
| Dimensions (W x H x D) mm | 71.8 X 90 X 65.5 | |||||
| KNX Bus Connector | 0.6 ~0.8 Ø, solid | |||||
| Input connectors | Screw terminal, 2.5 mm2 stranded ~ 4 mm2 Solid | |||||
| Tightening torque | Maximum 0.4 Nm | |||||
| Available colors | White & Light Gray | |||||
